Hybrid solar inverter 11000W / 150A 550V DC / για σύστημα 48V ή 52V με WiFi

Δωρεάν μεταφορικά στο κέντρο της Αθήνας.

Rated power: 11KVA/11KW
Parallel Capability: Yes, up to 6 units

INPUT:
Nominal Voltage: 230VAC
Acceptable Voltage Range: 170-280VAC(For personal Computer) / 90-280VAC(For Home Appliances)
Frequency: 50/60 Hz (Auto sensing)

OUTPUT:
Nominal Voltage: 230VAC±5%
Surge Power: 22000VA
Efficiency (Peak): 93%
Waveform: Pure Sinewave
Transfer Time: 15ms(For personal Computer) / 20ms(For Home Appliances)
No Load Power Consumption: < 70W
Dual Outputs: Yes

BATTERY:
Battery Voltage: 48VDC
Floating Charge Voltage: 54VDC
OverCharge Protection: 66VDC

SOLAR CHARGER & AC CHARGER:
Solar Charger TYPE: MPPT
Max.PV Array Power: 11000W(5500Wx2)
Max. PV Array Open Circuit Voltage: 500 VDC
MPPT Range @ Operating Voltage: 90VDC~450VDC
Maxmum Solar Charge Current: 150A
Maximum AC Charge Current: 150A
Maximum Charge Current: 150A

PHYSICAL:
Dimensions: D x W x H(mm) 710x590x260
Gross Weight (Kgs): 23.55
Communication Interface: USB/RS232/RS485/Wifi/Dry-contact

OPERATING ENVIRONMENT:
Operating temperature: -10°C to 50°C
Storage temperature: -15°C~ 60°C
Humidity: 5% to 95% Relative Humidity (Non-condensing)

Features:
1. Configurable color with the built-in RGB LED bar
2. Built-in Wi-Fi for mobile monitoring (APP is required)
3. Supports USB On-the-Go function
4. Optional 12V DC output
5. Built-in anti-dusk kit
6. LCD control module with multiple communication ports for BMS (RS485, CAN-BUS, RS232)
7. Configurable input voltage ranges for home appliances and personal computers via LCD control panel
8. Configurable AC/PV output usage timer and prioritization
9. Configurable AC/Solar charger priority via LCD control panel
10. Configurable battery charging current based on applications via LCD control panel
11. Compatible to utility mains or generator power
12. Auto restart while AC is recovering
13. Overload / Over temperature / short circuit protection
14. Smart battery charger design for optimized battery performance

Note:
The inverter contains WIFI module, which can be matched with the inverter and does not need to be purchased separately

Package includes:
1x Inverter unit
1x Manual
1x software CD
1x RS-232 cable
1x Parallel communication cable
1x Current sharing cable
1x DC Fuse
4x Cable gland
2sets x PV connectors
